Dual band IEEE 802.11 a/b/g/n/ac/ax standard Antenna w MHF
Dual band IEEE 802.11 a/b/g/n/ac/ax standard Antenna w MHF
Dual band IEEE 802.11 a/b/g/n/ac/ax standard Antenna w MHF
Dual band IEEE 802.11 a/b/g/n/ac/ax standard Antenna w MHF

Dual band IEEE 802.11 a/b/g/n/ac/ax standard Antenna w MHF

Embedded Antenna / WIFI Dual Bands

Feature

•Dualband IEEE 802.11 a/b/g/n/ac/ax standard

•Case mounting or on board mount

•High efficiency

•Quick integration

Add To Inquiry

DESCRIPTION

SPECIFICATION

OUR SERVICE

5GHz AP/Router Embedded Antenna WiFi for Internet of Things



The LYNwave AP/Router embedded antenna, ALX18M-092AA1-00 provides high efficiency and quick integration to deliver powerful performance. It can be used in multiple applications such as navigation, location and tracking devices, smart wearables devices, transportation, geofencing, agriculture and infrastructure.



Since LYNwave has strong R&D antenna hardware development capabilities with 50+ antenna design patents and is specialized in using computer simulation to design customized antennas, we will offer you the optimal OEM / ODM / JDM antenna with our skills and technologies. Contact LYNwave and we will provide comprehensive support for you.

z
Model Name ALX21M-222AA0-00
Frequency (MHz) 2400 ~ 2500 5150 ~ 5825
Peak Gain (dBi) 2.3 4.2
VSWR 2.0 : 1 2.0 : 1
Power (Watts) 1 1
Impedance (Ohms) 50 50
Dimension (mm) 13.1 x 9.7 x 8.5 x 0.3
Connector MHF compatible
Cable Length (mm) 35
Manufacturing 100% made in Taiwan
Lead Time 4~6 weeks
  • Innovative Customized Antenna Design Service
  • RF Antenna Design (Wi-Fi, LTE, GNSS, NFC, LPWAN, ISM, ZigBee, Bluetooth, Others)
  • Smart Antenna Design
  • Thermal Solution Design (Integrating Antennas & Heatsinks)
  • High Gain Patch Antenna Solution
  • Performance and Design Optimized for Both Internal and External Applications
  • 3D Simulation Pretest Provided
  • Extensive Lab and Field Testing Support
