High Efficiency Embedded Single Band PCB Dipole Antenna
The ALX17P-091XX0-00 is a high-efficiency PCB dipole antenna engineered for seamless integration into compact wireless systems operating in the 5GHz frequency band. Designed as an embedded antenna, it delivers a peak gain of 6.3dBi, optimized for Wi-Fi applications compliant with IEEE 802.11a/n/ac standards. The antenna is built on a PCB substrate and features an IPEX connector with a 230mm RF-1.13 low-loss coaxial cable, with customizable cable length options to accommodate flexible installation needs.
A key advantage of the dipole antenna lies in its structural simplicity and consistently reliable performance. Variations in the dipole gap have minimal impact on practical efficiency, making it a dependable choice for RF designs. This 5GHz PCB antenna offers omnidirectional radiation, ensuring stable signal transmission and reception across the frequency range without sensitivity to direction. Backed by LYNwave’s strict performance assurance, it is an ideal solution for meeting the rigorous demands of modern embedded modules.
Since LYNwave has strong R&D antenna hardware development capabilities and is specialized in using advanced computer simulation to create customized antennas, we will support you the optimal antenna with our skills and technologies. Custom tuned versions for different environments can be made. Contact LYNwave and we will provide comprehensive support for you.
| Model Name | ALX17P-091XX0-00 |
| Frequency (MHz) | 5450~5825 |
| Peak Gain (dBi) | 6.3 |
| VSWR | 2.0 : 1 |
| Power (Watts) | 1 |
| Impedance (Ohms) | 50 |
| Dimension (mm) | 33 x 24 x 0.6 |
| Cable Length (mm) | 230 (customized) |
| Connector | IPEX |
| Operation Temp (°C) | -40°C ~ +85°C |
| Lead Time | 4~6 weeks |
